MiniDSP DDRC-24 DSP Processor with Dirac Live

DDRC-24

Regular price$839.00
/

Buy now, pay later with: Zip Interest Free Afterpay Interest Free Humm Interest Free
  • Free Delivery Australia Wide
  • Local Australian Warranty
  • 1800 100 998 For Assistance

We take pride in our customer service and shipping times. Most products will ship within 1-2 business days. If there are any potential delays with products in your order, we will contact you.

All orders now come with free shipping Australia Wide.

We use a variety of shipping methods depending on the types of items purchased and their delivery location. This helps to ensure your items arrive safely and in a timely manner. If you are on a tight deadline or would like to know an estimated delivery date for your order, contact our friendly staff and they will be happy to assist.

DDRC-24, a USB DAC+DSP Digital Room Correction processor powered by Dirac Live in a tiny form factor

miniDSP introduces the DDRC-24, the world’s smallest Dirac Live® hardware processor. Dirac Live®, the world’s premier room correction solution, is now available in an unbelievably compact hardware unit. Powered by a 400 MHz Analog Devices SHARC processor, the DDRC-24 retains the 4-channel output of its sister unit, the miniDSP 2x4 Hd, in order to allow applications like subwoofer integration or even 2-way loudspeakers together with Dirac Live® room correction in a single tiny hardware platform. The matrix mixer and crossover functionality is accessed and programmed with miniDSP’s easy-to-use interface software. An all in one unit with USB DAC + Dirac Live Room Correction + Speaker processing.

I/O capabilities get an upgrade too, with the addition of USB audio streaming up to 192 kHz and a TOSLINK digital input. The miniDSP DDRC-24 will find application in full-sized hifi and home theater systems, on desktops, in cars, in recording studios anywhere a compact, powerful room correction processor is needed.

Features

  • ADSP21489 400MHz Sharc DSP floating point engine
  • XMOS Xcore200 for USB control and bidirectional audio streaming
  • 24 bit ADC/DAC resolution
  • Dirac Live 3.x  for miniDSP with 4 presets, fully configurable target curve
  • Unbalanced inputs switchable with a jumper between 4Vrms and 2Vrms
  • Toslink digital input
  • Unbalanced outputs: Max 2Vrms
  • USB Audio Class 2 Audio streaming with ASIO drivers, driverless under MAC OSx
  • 4 preset configuration, recallable via IR, Software
  • Wifi/Alexa voice control via WI-DG accessory

Now compatible with miniDSP Device Console


Product Downloads - Device Console

What's in the box?

  • 1 x DDRC-24 including Dirac Live license for miniDSP and DDRC-24 plugin
  • 1 x 12V power supply with UK/EU/US/AU plugs
  • 1 x shielded USB cable
  • 1 x IR remote
  • 1 x Dirac live license 3.x  for miniDSP,  full range correction
  • 1 x Device Console for DSP control automatically added to your UserDownloads section on purchase
  • (Optional if ordered) 1 x UMIK-1, USB microphone with unique calibration file for accurate acoustic measurements

Optional Accessories

  • WI-DG for Wifi/Alexa voice control of your unit. Note only the plugin is controllable via Wifi. Dirac Live still requires a USB connection unfortunately.
  • Audio RCA cables

NOTE: The UMIK-1/2 are measurement microphones approved by Dirac Research. Knowing the major effect a wrong calibration/measurement would have on the final results of Dirac Live tuning, we strongly recommend that you select a UMIK-1/2 microphone together with your platform for a plug&play experience leading to best results. Any issues related to 3rd party microphones such as ASIO/USB audio driver incompatibility/Latency problems or incorrect calibration process will not be under our support structure by our support team.

    Specifications

    Digital Signal Processor Engine Analog Devices Floating point DSP SHARC
    ADSP21489

    Internal Processing resolution
    & Sample rate

    32 bit / 48kHz

    Input/Ouput Configuration

    2 in / 4 out

    Audio Input Connectivity

    Unbalanced analog input, RCA terminated
    Stereo Digital Inputs: TOSLINK (optical)
    Stereo USB audio input: USB Audio
    Supported ASCR: 20~216kHz

    Audio Output Connectivity

    Unbalanced output, RCA terminated

    Input / Output Max Levels

    IN: 2Vrms / 4Vrms (jumper-selectable)
    OUT: 2Vrms

    Input Impendance
    10 kΩ
    Output Impedance 560
    Calibration Software DDRC-24 plugin
    Filtering Technology Dirac Live 3.x
    DSP Presets Up to 4 presets
    Dimensions 27 x 119 x 107 mm
    Power 12 VDC single supply
    2.1 mm round plug / 2.5W
