Exposure

Exposure XM9 Mono Power Amplifier Pair

$4,999

Seen it cheaper? Talk to us.Trade in your old amplifier typically $400–$900 toward this

In stock
Colour: Black

Pickup available at Alexandria Showroom · Usually ready in 2-4 days

Ships from SydneyIn stock · free insured AU shipping · we confirm your dispatch date within one business day·
Australian warrantyAuthorised dealer, local support
Installation availableSydney metro, quoted with the gear

FEATURES

  1. Large 200VA custom-made toroidal power transformer
  2. High quality all aluminium casework and extruded front panel
  3. High quality resistors & capacitors used in the signal path
  4. Cascode circuitry utilised for improved power supply immunity
  5. Toshiba bipolar output transistors for dynamics and performance
  6. 80 watts per channel into 8 ohms
  7. Unbalanced & balanced input selectable by internal link
  8. DC coupled throughout
  9. Electronic, non invasive current overload protection
  10. Bi-wire speaker outputs using high quality shrouded sockets
  11. Three year guarantee
  12. Available in black or titanium

SPECIFICATIONS

  • Power Output (1KHz) : 80 watts per channel into 8 ohms
  • Total Harmonic Distortion : @ 1KHz, rated power : 0.005%
  • Frequency Response : 20Hz - 20KHz .5dB
  • Input Sensitivity, Unbalanced ref 1KHz rated output : 1.6V RMS
  • Gain : Unbalanced input x16, 24dB @ 1KHz
  • Input Impedance, Unbalanced : 77K ohms
  • Signal to Noise, Unbalanced, ref 1KHz rated output : 95dB
  • Mains Supply : 110/120V or 220/240V @ 50/60Hz (factory set)
  • Power Consumption : 200W
  • Dimensions (WxHxD) : 218mm x 89mm x 363mm (inc knob)
  • Net Weight (unpacked) : 5kg
  • Gross Weight (packed) : 6kg
