Arcam

Arcam A5+ Integrated Amplifier

$1,595

Seen it cheaper? Talk to us.Trade in your old amplifier typically $400–$900 toward this

In stock SKU: A5+

Pickup available at Alexandria Showroom · Usually ready in 2-4 days

Ships from SydneyIn stock · free insured AU shipping · we confirm your dispatch date within one business day·
Australian warrantyAuthorised dealer, local support
Installation availableSydney metro, quoted with the gear

The A5+ features an enhanced power supply design and cutting edge wireless capabilities straight out of the box. Snapdragon Sound delivers uncompressed digital audio via Bluetooth, while Auracast enables multiple compatible headphones or speakers to share music wirelessly, with no pairing required.

With a wide array of digital and analogue inputs, including a meticulously tuned phono stage, the A5+ ensures impeccable sound quality for everything from vinyl to streaming.

  • Wireless audio with Bluetooth 5.4
  • Featuring Snapdragon Sound for wireless lossless audio
  • Featuring Auracast for connecting wireless headphones or speakers to play music in multiple spaces.
  • Hi-res audio digital inputs
  • ESS ES9018 DAC
  • Meticulously tuned phono stage
  • Class AB amplification
  • 2x 50 Watts (8Ω) Power Output
  • Compact remote control
  • Solid aluminium dials
  • Aluminium front, top, sides and rear panels

Specification

Continuous Power Output (0.5% THD), Per Channel
2 Channels Driven, 20 Hz - 20 kHz, 8 Ω 50 W
2 Channels Driven, 1 kHz, 4 Ω 75 W
Harmonic Distortion, 80% Power, 8 Ω at 1 kHz 0.003%
Analogue Inputs
Number of Inputs 3 (RCA Pairs)
Signal/Noise Ratio (A-Wtd, Ref. 50 W, 1 V Input) 106 dB
Frequency Response 20 Hz — 20 kHz ± 0.2 dB
Phono (MM) Input
Input Impedance 47 kΩ + 100 pF
Frequency Response (Ref. RIAA Curve) 20 Hz — 20 kHz ± 1 dB
Digital Inputs
Supported Sample Rates 192, 176.4, 96, 88.2, 48, 44.1 kHz
Bit Depths 24, 16 Bit
Frequency Response (Filter 1) 20 Hz — 20 kHz ± 0.2 dB
Signal/Noise Ratio (A-Wtd, Ref. 50 W, 0 dBFS) 109 dB
Headphone Output
Maximum Output Level (RMS) into 32 Ω / 300 Ω 2.5 V / 5 V
Load Range 16 Ω - 2 kΩ
Wireless Specifications
Bluetooth Version 5.4; A2DP Sink/Source, AVRCP, BLE, SBC, AAC, aptX, aptX HD and aptX Lossless, LE Audio, Auracast
Bluetooth Transmitter Frequency and Power 2,400 MHz to 2,483.5 MHz: <20 dBm
General
Mains Voltage 110–120 V or 220–240 V, 50–60 Hz
Power Consumption (Maximum) 350 W
Power Consumption (Standby) <0.5 W
Dimensions W x D (Including Speaker Terminals) x H (Including feet) 431 x 344 x 83 mm
Weight (Net) 8 kg
Weight (Packed) 11 kg
Supplied Accessories Mains Lead(s), Remote Control with 2 x AAA Batteries, Quick Start Guide, Important Safety Instructions
