Arcam A5+ Integrated Amplifier

Arcam  /  Integrated Amplifiers

A5+

$1,595.00
/
Buy now, pay later with: Zip Interest Free Afterpay Interest Free Humm Interest Free
  • Free Delivery Australia Wide
  • Local Australian Warranty
  • 1800 100 998 For Assistance

We take pride in our customer service and shipping times. Most products will ship within 1-2 business days. If there are any potential delays with products in your order, we will contact you.

All orders now come with free shipping Australia Wide.

We use a variety of shipping methods depending on the types of items purchased and their delivery location. This helps to ensure your items arrive safely and in a timely manner. If you are on a tight deadline or would like to know an estimated delivery date for your order, contact our friendly staff and they will be happy to assist.

Orders will usually take between 1-6 days for delivery, depending on your location and shipping method.

If your order has not been delivered within 7 days of shipping we recommend you reach out to us directly to investigate with Australia Post / Courier.

If for any reason you haven't followed up with us within 30 days of shipping, we'll be unable to guarantee your delivery of your item unless it has been returned to sender.

The A5+ features an enhanced power supply design and cutting edge wireless capabilities straight out of the box. Snapdragon Sound delivers uncompressed digital audio via Bluetooth, while Auracast enables multiple compatible headphones or speakers to share music wirelessly, with no pairing required.

With a wide array of digital and analogue inputs, including a meticulously tuned phono stage, the A5+ ensures impeccable sound quality for everything from vinyl to streaming.

  • Wireless audio with Bluetooth 5.4
  • Featuring Snapdragon Sound for wireless lossless audio
  • Featuring Auracast for connecting wireless headphones or speakers to play music in multiple spaces.
  • Hi-res audio digital inputs
  • ESS ES9018 DAC
  • Meticulously tuned phono stage
  • Class AB amplification
  • 2x 50 Watts (8Ω) Power Output
  • Compact remote control
  • Solid aluminium dials
  • Aluminium front, top, sides and rear panels

Specification

Continuous Power Output (0.5% THD), Per Channel
2 Channels Driven, 20 Hz - 20 kHz, 8 Ω 50 W
2 Channels Driven, 1 kHz, 4 Ω 75 W
Harmonic Distortion, 80% Power, 8 Ω at 1 kHz 0.003%
Analogue Inputs
Number of Inputs 3 (RCA Pairs)
Signal/Noise Ratio (A-Wtd, Ref. 50 W, 1 V Input) 106 dB
Frequency Response 20 Hz — 20 kHz ± 0.2 dB
Phono (MM) Input
Input Impedance 47 kΩ + 100 pF
Frequency Response (Ref. RIAA Curve) 20 Hz — 20 kHz ± 1 dB
Digital Inputs
Supported Sample Rates 192, 176.4, 96, 88.2, 48, 44.1 kHz
Bit Depths 24, 16 Bit
Frequency Response (Filter 1) 20 Hz — 20 kHz ± 0.2 dB
Signal/Noise Ratio (A-Wtd, Ref. 50 W, 0 dBFS) 109 dB
Headphone Output
Maximum Output Level (RMS) into 32 Ω / 300 Ω 2.5 V / 5 V
Load Range 16 Ω - 2 kΩ
Wireless Specifications
Bluetooth Version 5.4; A2DP Sink/Source, AVRCP, BLE, SBC, AAC, aptX, aptX HD and aptX Lossless, LE Audio, Auracast
Bluetooth Transmitter Frequency and Power 2,400 MHz to 2,483.5 MHz: <20 dBm
General
Mains Voltage 110–120 V or 220–240 V, 50–60 Hz
Power Consumption (Maximum) 350 W
Power Consumption (Standby) <0.5 W
Dimensions W x D (Including Speaker Terminals) x H (Including feet) 431 x 344 x 83 mm
Weight (Net) 8 kg
Weight (Packed) 11 kg
Supplied Accessories Mains Lead(s), Remote Control with 2 x AAA Batteries, Quick Start Guide, Important Safety Instructions
