Velodyne SC-IWDVR SubContractor In-Wall Passive Subwoofer

Model: SC-IWDVR | Warranty: 2 Years | Product Type: Subwoofer
Velodyne Velodyne SC-IWDVR SubContractor Series Subwoofer Subwoofer
  • Free ShippingFree Shipping Australia Wide
  • Secure ShoppingSecure Online Payment
  • $3,499.00

  • American Express
  • Apple Pay
  • Google Pay
  • Mastercard
  • PayPal
  • Shop Pay
  • Visa
  • Free ShippingFree Shipping Australia Wide
  • Secure ShoppingSecure Online Payment

Key Information

  • Driver Size: 14”
  • Frequency Response: 22 - 120 Hz
  • Amplifier Output: N/A

The SubContractor Subwoofers Series offer 2 subwoofer sizes with separate amplifiers that are meant for in-wall applications.

Imagine a home cinema in the living room ambience, without any technical equipment: No disturbing loudspeakers, well hidden electronic components, retractable screen or large screen and above all no visible cables. So far everything is possible. It becomes difficult, however, if this living and entertainment room is still supposed to offer a cinema-quality sound experience with bloodcurdling low bass, because bass speakers cannot be hidden away easily for many reasons.

"Bass cannot be located anyway!" Perhaps you have heard this claim somewhere before. In fact, there is a kernel of truth in the statement that the human ear has difficulty locating low frequencies. But this is only true for frequencies well below 80 Hz. This also means, however, that the subwoofer should not emit any frequencies above this limit, which most conventional subwoofers are unable to do.

Truly potent subwoofers that can reproduce the lowest frequencies without drifting unintentionally into the frequency spectrum above 80 Hz cannot be made arbitrarily small for physical reasons. The Velodyne SubContractor series now offers you all possibilities to integrate a powerful and clean low bass unobtrusively into your listening room.



Key Features

Easy to Install

Easy install in retro fit or new construction with integrated cabinet. Just cut, plug and play.

Low-Profile Design

The low-profile design virtually disappears, fitting flush in a standard 2x4 wall

System friendly features

12V trigger, IR repeater jack, RS-232 controllable (Crestron Certified)

Almost invisible but Powerful

Amazing deep, powerful, low distortion bass performance that integrates into the wall

Technical Specification

SC-600 IW SC-IWDVR SC-600D SC-1250
Driver Two 6.5" active drivers
Two 12.5" x 3" passive drivers
4" x 14" rectangular driver
(3" x 12.25" piston dimensions)
-
Amplifier Class D - 400 watts dynamic
200 watts RMS power
3000 watts dynamic
1250 watts RMS power
Frequency Response: (± 3 dB) 34.25 - 180 Hz 22 - 120 Hz -
THD < 5 % (typical) -
High Pass Crossover - 80 Hz (6 dB / octave)
Low Pass Crossover - 30 - 160 Hz, defeatable, 24 dB / octave slope
Phase - 0°, 90°, 180°, 270°
Magnet Structure 4 lbs. each active
8 lbs. total
275 oz. Neodymium motor structure -
Voice Coil 4-layer copper 3" Dual Layer inner/outer wind -
Input - Line and Speaker level
Output - Line-level, 80 Hz up, speaker level for up to two subwoofers
Dimensions (H/W/D) (includes feet, flange and/or knobs) 18.6" x 16.5" x 4.3" (47.2 x 42 x 11 cm) 28.5" x 14" x 3.5" (72 x 35.56 x 8.89 cm) 3.6" x 17" x 13" (9 x 43.3 x 33 cm) 3.6" x 17" x 12.5" (9 x 43.2 x 31.8 cm)
Shipping Weight (approx) 22 lbs. 43 lbs. 17 lbs. 30 lbs.
