- 5 HDMI Inputs / 1 HDMI Output
- 100W @ 8 Ohm
- HEOS Music Streaming
Enjoy Denon DRA-800H two-channel Hi-Fi network receivers high quality audio performance listening to analogue and digital sources. With FM/DAB+ radio, a wide array of connectivity including phono input, network integration and HDMI you will upgrade your listening and home theatre experience. Featuring advanced custom amplifier design and a strong power supply, the DRA-800H ensures your loudspeakers drive detailed, precise imaging and impactful sound. With 4K Ultra HD HDMI and the latest wireless music streaming technologies (Wi-Fi, AirPlay 2, Bluetooth and HEOS Built-in), the DRA-800H integrates seamlessly with your TV, music services and Hi-Fi system. Enjoy network streaming and USB front-panel audio playback of MP3, WAV, FLAC, ALAC and DSD (2.8/5.6MHz) files. Equipped with A/B speaker terminals, dual subwoofer pre-outs, three digital and two analogue inputs, one phono (MM) input and ARC for TV audio, the DRA-800H delivers a premium stereo listening experience for your music collection and home theatre viewing.
- Two-channel Hi-Fi network receiver with 100W per channel: Enjoy Denon Hi-Fi sound seamlessly integrated with the latest receiver technology
- Expert sound engineering: Carefully selected Hi-Fi parts, dedicated circuitry with short, straight paths between power supply, signal and amplification to deliver a premium audio experience
- Denon Hi-Fi amplifier: Discrete amplification for left and right channels — feel the power and hear every detail as the artist intended with 100W power per channel (8 ohm, 20Hz – 20kHz, THD: 0,07%, 2ch driven)
- Integrated phono input and MM equalizer: Directly connect your turntable and enjoy the world of vinyl
- FM analogue radio and digital DAB+: Listen to the full bandwidth of local radio stations without the need of network connection
- Hi-Res audio certified: Network and front panel USB allows for gapless playback of high-resolution audio including 192kHz/24bit FLAC, WAV, ALAC and DSD 2.8/5.6MHz
- Supports Spotify, Amazon Music, TuneIn, Deezer and more: Wirelessly stream and enjoy the most popular music services
- HEOS Built-in wireless multi-room music streaming technology: Listen from any room for a connected, whole-home audio experience
- Amazon Alexa, Google Assistant and Apple Siri voice control: Use your voice to control the DRA-800H and wireless music services hands-free
- Direct access tone control and direct mode: Fine-tune your treble, bass and balance audio settings for pristine listening
- Premium DAC: Hear the fine details of your music with the 32-bit 8ch AKM DAC — operates in double differential mode to deliver high-resolution audio decoding with multiple lossless files
- 4K/60 Hz, HDR10, HLG, 4:4:4 colour resolution and BT.2020: Provides the greatest video quality with exceptional brightness, contrast and colour
- Award-winning Denon Setup Assistant and graphical user interface: Easy and intuitive out-of-box setup experience
- Smart TV compatibility: Easily control the DRA-800H with most TV remotes via HDMI-CEC
- Analogue and digital audio inputs: No limitations connecting all your sources
- Speaker A/B and Zone 2 pre-out: Connect two pairs of speakers for easy A/B switching, or extend your system to a second room and listen to a different source in Zone 2 via pre-outs
- Four Quick Select Buttons: Featured on the front panel — store your preferred audio settings for each source
High Performance Discrete 2 Channel Amplifier
The DRA-800H Hi-Fi network receiver amplifier is specifically designed to meet the needs of your two-channel system. Featuring a custom discrete high-current power amplifier, symmetrical design and an OFC (oxygen-free copper) winding power transformer, the DRA-800H delivers maximum performance and 100W of power per channel (8 ohm, 20Hz – 20kHz, THD: 0,08%, 2ch Driven). With low impedance drive capability, it offers greater stability with a wide range of floor-standing and bookshelf loudspeakers for balanced, quality sound, every time. Auto ECO mode helps reduce power consumption, without sacrificing audio quality.
Expert Sound Engineering
Denon sound engineers use carefully selected Hi-Fi parts, including custom resistors and audio grade capacitors, to tune the stereo receiver. Using the design principles found in Denon award-winning amplifiers, the DRA-800H features a symmetrical layout, double differential DAC circuit and analogue preamp circuits that don’t interfere with the power supply. The dedicated circuitry with its short, straight paths between the power supply, signal and amplification ensure your loudspeakers drive detailed and precise imaging.
Enjoy a wide array of music streaming service including Spotify free and premium, Deezer, TIDAL, Amazon Music and many more. Explore the world of internet radio with TuneIn and enjoy distortion free radio from all over the globe.
Enjoy superb audio fidelity with your favourite high-resolution audio tracks. The DRA-800H with AKM 32-bit D/A converters features high-resolution audio decoding with multiple lossless file types, including ALAC, FLAC and WAV at up to 24-bit/196-kHz. It’s also compatible with 2.8/5.6-MHz DSD files (DSD is the audio coding format of SACD). Play them from memory devices via the front panel USB, or over network sources. The DRA-800H also supports other file types such as MP3 and WMA.
Speaker A/B and Zone 2 Pre-Out
Connect two pairs of speakers for easy A/B switching. Or, extend your system to a second room and listen to a different source in Zone 2 via pre-outs.
Phono Input for Turntable/Vinyl Support
For nearly 50 years, Denon has been developing turntables, cartridges and phono pre-amps. With the included phono input, the DRA-800H lets you connect your turntable and play vinyl records. Enjoy your collection with exceptional quality and sound.
Dual DAC Differential Circuit
The DRA-800H utilizes an eight-channel premium DAC to deliver amazing stereo imaging and detail. By assigning two DAC’s per channel including the subwoofer output, hear increased dynamic range and improved signal to noise (S/N).
Advanced HDMI Video Section
Enjoy your favourite movies, shows and games with the best picture quality available.
Advanced HDMI Video Section with ARC
The DRA-800H features 5 HDMI inputs and 1 output — that support full 4K Ultra HD 60Hz video, 4:4:4 Pure Colour sub sampling, High Dynamic Range (HDR10), Hybrid Log-Gamma (HLG), ARC, 3D, and BT.2020 pass-through support for exceptional colour, clarity and contrast. Audio Return Channel (ARC) support enables the transmission of audio directly from the smart TV to the receiver through the connected HDMI cable.
Advanced Video Controls
HDCP 2.3 processing is available on all HDMI ports, letting you enjoy copy-protected content totally uninhibited. Enjoy seamless compatibility with the latest HD and Ultra HD TVs, Blu-ray players and game consoles.
Easy Setup Experience
The included DRA-800H Quick Start Guide provides simple, clear instructions for how to get started. Once you connect your TV to the DRA-800H via HDMI, the exclusive Denon Setup Assistant appears on your TV screen to walk you through setup, step-by-step.
Built-In Bluetooth and Wi-Fi Connectivity
The heart of your wireless network. For Bluetooth, Wi-Fi and AirPlay 2 wireless streaming connectivity, the Denon DRA-800H is equipped with an advanced dual antenna transceiver system for robust streaming even in congested urban environments. Enjoy listening to your favourite audio content wirelessly from your smart devices.
With HEOS Built-in technology play the same song in every room or select a different song for each connected room — the choice is yours. HEOS works with Amazon Alexa and Google Assistant, providing effortless voice control.
HEOS supports free and premium Spotify, Amazon Music, Deezer, TuneIn, Sound Cloud, TIDAL and more.
Quick Selects for User Friendly Audio Tuning
The Denon DRA-800H front panel features four Quick Select buttons that store your preferred audio settings for each source. Switch between TV audio, Blu-ray, media players and more, and the DRA-800H adjusts the EQ settings to your preferences for that media source. Use the buttons on the front panel or opt for the same Quick Select on the receiver remote for faster control. Now allows for one-push all zone stereo mode via Quick Select.
Auto Low Latency Mode
Auto Low Latency Mode (ALLM) ensures Xbox One users have a more responsive and immersive gaming experience when connected with select TV models that also support ALLM.
Works with Latest Voice Assistants
Enjoy effortless voice control and total flexibility from the leading voice services. Using a smart speaker or your phone, speak commands with Amazon Alexa, Google Assistant, Apple Siri. Ask to play your favourite music, turn the volume up, skip to the next track, switch inputs and more. Switch between voice services or pick a favourite to use — the choice is yours. Functionality varies by voice agent.
Works with Amazon Alexa
Control the DRA-800H hands-free with Amazon Alexa and your voice. Adjust the volume, skip to the next track, switch inputs for your different media players and more — “Just Ask.” Download the free HEOS Home Entertainment Skill to enable Amazon Alexa voice commands for your DRA-800H, HEOS devices and other Denon products with HEOS built-in. Requires Alexa app and Amazon Echo, Dot or equivalent.
Works with Google Assistant
Start music in the HEOS app, then ask your Google Assistant to control volume, play, pause, skip tracks and more.
AirPlay 2 + Apple Siri Voice Control
Use AirPlay 2 to stream music wirelessly to the AV receiver, or group with other AirPlay compatible speakers to fill your home with music.
Stream audio from your favourite music services like Apple Music and Spotify or watch videos from services like YouTube and Netflix from any iPhone, iPad, Mac or Apple TV and hear the audio perfectly synced to your speakers AirPlay 2 sources.
AirPlay 2 also supports multi-room audio – wirelessly stream content to multiple AirPlay 2 compatible devices simultaneously with improved audio buffering to ensure smooth audio playback. AirPlay 2 provides control and grouping of compatible audio devices within the Apple Music or Home app. Use AirPlay 2 in-app or with your voice via Siri.
HEOS Built-In for Wireless Music Streaming
Stream your favourite music from anywhere and everywhere around your home with HEOS Built-in technology. Enjoy high quality music from a wide range of streaming services including Spotify®, TuneIn, Amazon Prime Music, Soundcloud®, TIDAL, Napster, Deezer or local music sources. Control it all seamlessly with the free HEOS app.
Select the Perfect HEOS for Your Setup
With the HEOS multi-room function, the Denon DRA-800H can connect with any other product with HEOS Built-in, like HEOS speakers, to play music throughout your entire home. Play the same song in every room or select a different song for each connected room — the choice is yours.
HEOS 1: Ideal for damp environments or outdoors.
HEOS 3: The perfect choice for medium sized rooms.
HEOS 5: Bring beautiful sound into larger rooms.
HEOS 7: Get the party going in wider spaces and open areas.
Custom Install Ready
The Denon DRA-800H features external control and IP control capabilities for easy customization and compatibility with third-party integration solutions. It offers IP control capability for major third-party control devices, as well as Control4 SDPP (Simple Device Detection Protocol) certification for seamless integration with Control4 home automation equipment. An IR (infrared) remote control jack is on the rear panel for remote control compatibility with other components in your home theatre system.
100+ Years of Firsts in Audio Technology
Founded in 1910, Denon has a deep heritage of “firsts” in audio technology — from Japan’s first audio electronics manufacturer, to producing the world’s first commercial CD player and Dolby Atmos-enabled AV receiver. This focused investment in audio R&D ensures you get the latest technology and highest quality with every listening experience.
|Digital In: USB-B / Optical / Coaxial / USB-A||- / 2 / 1 / 1|
|Sample Rate Digital In||192 kHz / 24-bit|
|USB-A: DSD / WAV / FLAC / AIFF / ALAC||<=5.6 / 192 / 192 / - / 192|
|Tuner: DAB / DAB+ / FM (RDS)||✓ / ✓ / ✓|
|Bluetooth / aptX / NFC||✓ / - / -|
|Streaming Audio From PC||✓|
|Wi-Fi / Wired LAN||✓ / ✓|
|Spotify Connect / Tidal / Deezer / Others||✓ / ✓ / ✓ / ✓|
|Amazon Prime Music / Pandora||✓ / ✓|
|HEOS Multiroom and Streaming||✓|
|Voice Control - Amazon Alexa / Google Assist / Apple Siri||✓ / ✓ / ✓|
|DSD-Audio Network Streaming||✓ / ✓ / ✓|
|Lossy Formats: MP3 / WMA / AAC||✓ / ✓ / ✓|
|Lossless Formats: DSD / FLAC HD 192/24 / ALAC 96/24 / WAV 192/24 / AIFF||✓ / ✓ / ✓ / ✓ / -|
|Remote APP: iDevice / Android||✓ / ✓|
|Wide Range Amplifier||✓|
|Power Amp Discrete Construction||✓|
|Balance / Bass / Treble / Loudness||✓ / ✓ / ✓ / -|
|Inputs / Outputs|
|Digital in: USB-B / Optical / Coaxial / USB-A||- / 2 / 1 / 1|
|Phono Input: MM / MC||✓ / -|
|Pre-Out / Main-In||Subwoofer / Zone 2|
|HDMI: Inputs / Outputs||5 / 1|
|Gold Plated Cinch||✓|
|Speaker A / B||✓|
|Number of Terminals||4|
|Remote Control Bus In / Out||✓ / -|
|HEOS Link Compatibility: IR / IP||✓ / ✓|
|Output Power 8 Ohm (20 Hz - 20 kHz, T.H.D. 0.07%)||100 W (0.08%)|
|Total Harmonic Distortion||0.01%|
|Input Sensitivity: MM||2.5 mV / 47 kohm|
|Signal to Noise Ratio: MM / MC||74 dB / -|
|Input Sensitivity: High Level||200 mV / 47 kohm|
|Signal to Noise Ratio: High Level||98 dB|
|Treble Control||±6 dB at 20 kHz|
|Bass Control||±6 dB at 20 Hz|
|Available Colours: Black / Premium Silver||✓ / -|
|Metal Front Panel||✓|
|Power Consumption||220 W|
|Power Consumption No-Sound (ECO On / Off)||29 W / 39 W|
|Standby Consumption||0.1 W|
|Auto Power Off||✓|
|Detachable Power Cable||✓/td>|
|System Remote Function||✓|
|Maximum Dimensions (W x D x H)||434 x 339 x 151 mm|
|Carton Maximum Dimensions (W x D x H)||523 x 435 x 232 mm|
|Carton Weight (Inc. Product)||10.3 kg|
