Blustream SW41AB-V2 4-Way 4K HDMI 2.0 HDCP 2.2 Switch

The SW41AB-V2 is a 4-Way HDMI switch with integrated audio breakout. The switch supports full HDMI 2.0 and HDCP 2.2 with video resolutions up to and including 4K @ 60Hz 4:4:4.

Features

• Features 4 x HDMI inputs which can be switched to single HDMI output

• Supports full HDMI 2.0 specification 4K UHD video (4K @b60Hz 4:4:4)

• HDCP 2.2 compliant

• Supports 3D signal display

• Supports all industry standard video resolutions including VGA-WUXGA and 480i-4K

• Supports all known HDMI audio formats including Dolby TrueHD, Dolby Atmos, Dolby Digital Plus and DTS-HD Master Audio transmission

• HDMI audio breakout to analogue L/R audio and coaxial digital outputs concurrently

• Control via front panel, RS-232 and IR

• Advanced EDID management

Specifications

• Video Input Connectors: 4 x HDMI Type A

• Video Output Connectors: 1 x HDMI Type A

• Audio Output Connectors:1 x RCA (S/PDIF) & 1 x Analogue audio L/R (3.5mm stereo jack)

• IR Input Ports: 1 x 3.5mm stereo jack

• RS-232 Serial Port: 1 x DB-9, female

• Casing Dimensions (W x H x D): 196mm x 41mm x 94mm

• Dimensions Including Connections (W x H x D): 196mm x 41mm x 104mm

• Shipping Weight: 0.9kg

• Operating Temperature: 32°F to 104°F (0°C to 40°C)

• Storage Temperature: -4°F to 140°F (-20°C to 60°C)

• Power Supply: 5V/2A DC

Box Contents

1 x SW41AB-V2
1 x SW41 Remote
1 x 5V/2A DC Power Supply
1 x User Manual
